• Wide compatibility range,modularized design, easy to changeover
• Whole tray/ flying probe test
• Fully automatic calibration tooling, ensuring test accuracy of voltage and internal resistance
• Automatic calculation of K value and equipped with MES interface
• Unique wiring anti-interference design
Items | Parameters |
First Time Yield | 99.9% |
Positioning Accuracy | 0.5mm |
Equipment Capacity | ≥90PPM |
Voltage Testing Accuracy | a)Voltage range:DC 0~10000mV b)Test accuracy:±0.0020%rdg.±12μm c)Cylindrical cell voltage testing accuracy:±0.1mV |
| Internal Resistance Testing Accuracy | a)Range of internal resistance:0μΩ~3KΩ b)Instrument accuracy:±(0.5%rdg.+10dgt.) c)Testing frequency:1KHz±0.2Hz d)Testing accuracy:±0.03mΩ~±0.1mΩ |
