• Wide compatibility range, modularized design, easy to changeover
• Fully automatic loading and unloading; Odd-even segment test
• Wireless power module calibration tooling, regularly calibration of module accuracy
• Titans' customized software, for real-time cell data acquisition and DCIR calculation
• Calibrating the current and voltage with power calibration tooling
Items | Parameters |
First Time Yield | 99.9% |
Positioning Accuracy | 0.5mm |
Equipment Capacity | ≥90PPM |
Module Spec. | 20A/30A/60A/100A/150A |
Discharging Voltage Range | 1500-5000mV |
Voltage Testing Accuracy | ±0.05%FS |
Current Range | （0.1%-100%）of FS |
Voltage Testing Range | 0-5000mV |
Discharging Measurement Time | Designed according to customer demands |
Sampling Frequency | 1KHZ |
